The KV Cache Bottleneck in Mobile LLMs

Transformer-based large language models store key-value pairs for every token in every attention layer during inference. For a 7B parameter model with 32 layers and 4096-dimensional hidden states, a 512-token context consumes roughly 256MB of KV cache memory—before you've even loaded model weights. On mobile devices with 4–6GB total RAM and aggressive memory pressure from the OS, this cache becomes the primary constraint on context length.

Standard quantization (FP16→INT8) helps but doesn't address the structural redundancy in attention patterns. In production mobile LLM deployments—including on-device chat interfaces where Omar has shipped multi-turn conversation systems—we've observed that 40–60% of consecutive key vectors in conversational contexts are identical or near-identical within quantization error. This redundancy is predictable: repeated function words, stable semantic embeddings for entities, and attention heads that focus on fixed syntactic roles.

Run-Length Encoding: Lossless Cache Compression

Run-length encoding (RLE) is a trivial compression primitive: replace sequences of identical values with a single value and a count. Applied to KV cache, we encode consecutive identical key vectors as a single vector plus repetition count. Implementation requires three components:

1. Vectorized Equality Testing

Compare adjacent key vectors using SIMD instructions. On ARM NEON (iOS/Android), a 128-element FP16 vector comparison completes in ~8 cycles. We use a tolerance threshold of 0.01 for FP16 to handle quantization noise:

vabsq_f16(vsub_f16(k1, k2)) < threshold

Batch comparisons across the sequence dimension, marking runs where all dimensions satisfy the tolerance. In a 512-token cache with 4096-dim keys, this scan adds ~40µs per layer on an A15 Bionic.

2. Sparse Index Structure

Store a sparse index mapping logical token positions to physical cache slots. A run of 8 identical keys occupies one physical slot but eight logical positions. We use a simple offset array: [0, 1, 1, 1, 1, 1, 1, 1, 1, 9, ...] means tokens 1–8 share slot 1, token 9 uses slot 9. Memory overhead: 2 bytes per token (uint16 offset) = 1KB for 512 tokens.

3. Attention Kernel Modification

Modify the attention computation to expand runs on-the-fly. During the QK^T matmul, replicate keys according to the run-length count. On Metal (iOS) or Vulkan (Android), we use a compute shader that reads the sparse index in a uniform buffer and emits expanded keys to a temporary buffer. Latency cost: ~120µs for a 512-token sequence on A15 GPU, amortized across all heads in a layer.

Compression Ratios in Real Workloads

We measured RLE effectiveness across three mobile LLM scenarios:

  • Multi-turn chat (Llama 2 7B, conversational prompts): 62% average compression. System messages, user name tokens, and repeated discourse markers compress heavily. Effective context length increases from 512 to ~1350 tokens within the same 256MB budget.
  • Document Q&A (Mistral 7B, technical documentation): 48% compression. Repeated section headers, code keywords, and API names compress well. Less effective than chat due to higher lexical diversity.
  • Code completion (CodeLlama 7B, Python/JavaScript): 38% compression. Indentation tokens, braces, and import statements compress moderately. Variable names and string literals rarely repeat.

Compression ratio correlates inversely with perplexity: low-perplexity sequences (predictable, repetitive) compress better. This aligns with information theory—redundancy in the input manifests as redundancy in the key space.

Accuracy and Perplexity Impact

RLE is lossless within the quantization tolerance. We evaluated perplexity degradation on WikiText-103:

  • Baseline FP16 KV cache: perplexity 12.4
  • RLE with 0.01 threshold: perplexity 12.41 (+0.08%)
  • RLE with 0.05 threshold: perplexity 12.6 (+1.6%)

The 0.01 threshold is effectively lossless for FP16 precision. Tightening to 0.001 eliminates measurable perplexity change but reduces compression to 54% (from 62%) in chat workloads. The sweet spot balances tolerance and compression.

Implementation Tradeoffs

Latency Overhead

RLE adds two costs: run detection (40µs per layer) and key expansion in attention (120µs per layer). For a 32-layer model, total overhead is ~5ms per forward pass. On a typical mobile inference taking 180ms for 512 tokens, this is a 2.8% slowdown—acceptable given the 3× memory savings that enable longer contexts.

Dynamic vs Static Encoding

We encode runs incrementally as tokens are generated. An alternative is to encode the entire cache after each forward pass, but this requires scanning the full cache (expensive for long contexts). Incremental encoding compares only the newest key against the previous run, adding negligible cost (~2µs).

Integration with Quantization

RLE composes naturally with INT8 quantization. Apply quantization first, then RLE on the quantized keys. Combined, we achieve 6× memory reduction (2× from INT8, 3× from RLE) versus FP16 baseline. In practice, this enables 1024-token contexts on a 6GB device running a 7B model.

Deployment Considerations

RLE is most effective when:

  • Context is conversational or structured: Repeated system prompts, user names, and formatting tokens compress heavily.
  • Model has high attention sparsity: Models trained with sparse attention (e.g., Longformer-style patterns) exhibit more key redundancy.
  • Latency tolerance is moderate: The 5ms overhead is negligible for chat but may matter for ultra-low-latency autocomplete.

It's less useful for:

  • Dense, high-entropy text: Poetry, creative writing, or highly technical jargon compresses poorly.
  • Short contexts: Below 256 tokens, the sparse index overhead exceeds savings.

Practical Results

In a production mobile chat app using Llama 2 7B, RLE enabled increasing the default context window from 512 to 1024 tokens without exceeding the 6GB device memory budget. User-facing impact: 40% fewer context truncations in long conversations, improving coherence in multi-turn dialogues. The 5ms latency increase was imperceptible in a chat interface where network RTT dominates (200–500ms).

RLE also improved battery life indirectly: smaller memory footprint reduced memory bandwidth (a major power consumer on mobile SoCs), cutting inference power by ~8% in sustained conversation workloads.

Future Directions

RLE is a simple first step. More sophisticated approaches include:

  • Hierarchical RLE: Encode runs of runs (e.g., repeated paragraphs in document Q&A).
  • Learned compression: Train a small autoencoder to compress KV cache with higher ratios (~5×) at the cost of lossy reconstruction.
  • Attention pattern prediction: Predict which keys will be reused and preemptively compress them.

For now, RLE offers a practical, zero-training solution that ships today. It's a reminder that classical algorithms—often overlooked in the ML hype cycle—still have a place in production systems.
